Wedge Wire Screens for Food Processing

Product Code: 2697
Category:Lauter Tun Screen
Material:stainless steel
Properties:wedge wire screen
Application:in food processing

Email to Us Start Order

Description of Wedge Wire Screens for Food Processing

Wedge Wire Screens are very effective in wells of this type since they can be manufactured with very small slot size and yet still maintain the necessary open area to minimize friction head loss. Most continuous wire wrap screen is manufactured from stainless steel rather than carbon steel in order to avoid problems which often leads to accelerated corrosion.

Our wedge wire screens are used in various food processing applications as well as for the de-watering of waste water in meat, poultry and vegetable processing industries


Features of Wedge Wire Screens for Food Processing


High mechanical strength, can withstand greater pressure
Uniform aperture, form uniform filter cake, beneficial backwash regeneration
Wedge-shaped filter gap, improve backwash regeneration capacity
High pressure, high temperature, anti-aging, corrosion resistant, available for many types liquid.
Almost two-dimensional filter, without particle accumulation, can gather energy when backwash, good backwash effect.


Applications of Wedge Wire Screens for Food Processing


You’ll see our stainless steel flat panels, cylinders and sieves at work in numerous areas.

Flat, framed or unframed wedge wire screen panels are used for:

• Filtration
• Lauter tun screen or wedge wire screen used in breweries
• Sizing and separation
• Fluid bed dryers or coolers
• Washing
• Various vibratory screening applications
• and more

Stainless steel sieve screens are used for:
• Processing corn for corn starch
• Processing sugar
• Sizing and washing potatoes, vegetable and cereal
• and more

Cylinders or half cylinders (added to an auger) are used for:
• Separating solids from liquids
• Used in a multitude of screw press applications
• and more

Not sure exactly what type of wedge wire screen will suit your application? Then let us help you select the right screen. We’ll customize your screens to fit any screening equipment in any specified width and length. Plus, size, shape and spacing of profile wire will be engineered to meet your special job requirements.
 Wedge Wire Screens in Food Processing

Specification of the Wedge Wire Screens for Food Processing

Wedge Wire Screens in Food Processing


Wedge wire screen panel


stainless steel (304,316etc.)

Wedge Wire (mm):

Width : 0.75 1.50 1.80 2.30 3.00 3.30 3.70

Height : 1.50 2.00 2.50 2.70 3.60 4.30 4.70 5.60 6.30 7.00

Support Rod (mm):

Width : 1.00 1.80 2.00 3.00 4.00 5.00

Height : 2.00 2.50 3.00 5.00 6.00 8.00


from 1 inch -----45 inch.


lengths up to 6 meters.

Slot Size:

0.02,0.05,0.1 0.15, 0.20, 0.25, 0.30,....., 3.00 also achieved request.




Other specifications can be customized according to your requirement

Production And Sales of Wedge Wire Screens for Food Processing

Package: in wood case

Delivery Time: 5-25 days.
