Stainless Steel sintered filter

Product Code: 1690
Category:Sintered Metal Mesh Filter
Material:stainless steel 304,304L,304HC,316,316L,321,430 or as per your request.
Properties:Sintered filter
Application:water treatment, oilfield, mining, food industry, chemical industry, papermaking industry, decoration.

Email to Us Start Order


Author: Jane
Email:sales@ubooem.com

Description of Stainless Steel sintered filter


    The Stainless Steel Sintered Filter adopts sintered stainless steel fiber felt, has high-pressure, high temperature and chemical corrosion resistance. Stainless Steel Sintered Filter also has good air permeability, high dirt holding capacity and long-life service time can repeat use by clean, is the ideal filter element for petroleum, chemical and synthetic fiber industries.

Stainless Steel sintered filter

Application for Stainless Steel sintered filter:

Stainless Steel Sintered Filter is mainly used for macromolecule polymer filtration, high temperature gas filtration, hydraulic system filtration, high-precision ink filtration, pre-filtration of high-precision membrane, catalyst carrier and regeneration, food, drink and pharmaceutical.

characteristic for Stainless Steel sintered filter:

Besides those mentioned above, MWC elements have also superior corrosion andabrasion resistance,especially suitable for fine filtration of high temperature, high pressure and viscous fluids.In comparison to the particle size distribution of powder materials, the range of diameters of the fibres is very uniform,resulting in an equally narrow range of pore diameters. This ensures an optimal ratio of filter grade to permeability.

The Products of UBO Company:

1. UBO is a professional manufacturer of filtration equipment, purifying equipment, oil-water separators and high-precision cartridges.
2. We have Certification: ISO14001:2004 international quality certificate and ASME certificate with U stamp, NB Certificate with NB stamp. Design License for Pressure Vessel(category I,II), Manufacturing License for Pressure Vessel(A1,A2).
3. Our Client: SINOPEC and the member of No.1 CNTC energy-net, CNPC, CNOOC companies.
4. Our products are mainly used in electric power, petrochemical, metallurgy, medicine, semiconductor and aerospace industries.

Stainless Steel sintered filter

Specification of the Stainless Steel sintered filter


Stainless Steel sintered filter

Small volume stainless steel sintered hydraulic support backwash filter element
Mesh/Inch Wire Diameter(mm) Aperture (mm) Filtration Area % Mesh/Inch Wire Diameter(mm) Aperture
(mm)
Filtration Area%
5 1.00 4.08 64 100 0.11 0.144 32
6 0.90 3.33 62 120 0.09 0.122 33
8 0.70 2.47 61 150 0.065 0.104 38
10 0.50 0.04 64 200 0.05 0.077 37
12 0.50 1.62 59 200 0.04 0.084 47
14 0.50 0.50 52 250 0.04 0.062 37
16 0.35 1.24 61 250 0.035 0.067 43
18 0.28 1.31 64 250 0.03 0.072 50
20 0.35 0.92 52 300 0.04 0.045 28
24 0.35 0.71 45 300 0.03 0.055 42
28 0.35 0.56 38 325 0.035 0.043 30

Production And Sales of Stainless Steel sintered filter


Stainless Steel sintered filter
