Sintered Metal Powder Filters

Product Code: 1706
Category:Sintered Powder Filter
Material:stainless steel 304,304L,304HC,316,316L,321,430 or as per your request.
Properties:Sintered filter
Application:filtering gas, liquid, and fuel oil. It is widely applied in petroleum, chemical, tractor

Email to Us Start Order


Author: zhaozhao
Email:sales@ubooem.com

Description of Sintered Metal Powder Filters


Sintered Metal Powder Filters is made by sintering fine metal particles with special process, which has good permeability, high precision, excellent strength and ductility. It has better performance than that filter made of paper, copper wire and other fiber cloth, and easy to removal and clean.

Sintered Metal Powder Filters can be made of stainless steel powders, bronze powders, nickel powders, titanium powders, high temperature alloy powders. We also can provide other kind of material if you required.


Application for Sintered Metal Powder Filters:


Sintered Metal Powder Filters can be used for filtering gas, liquid, and fuel oil. It is widely applied in petroleum, chemical, tractor, airplane and ship industries, and also applied as the filter element of pneumatic and hydraulic circuit.


Features for Sintered Metal Powder Filters:


1) high precision filter: pore stability, will not change the pore pressure changes with the phenomenon. Can effectively remove suspended solids and particulates, excellent filtration, purification effect.

2) permeability, pressure loss is small. Filter composed entirely of spherical powder, high porosity, pore size uniformity and smooth, the initial resistance is small, easy cleaning, regeneration ability, long service life.

3) high mechanical strength, good rigidity, good plasticity, anti-oxidation, corrosion protection without additional framework support, installation and use, easy maintenance, assembly, and can be welding, bonding and mechanical processing.

4) uniform porosity, especially for fluid distribution, homogenization treatment uniformity requirements of the occasion.

5) forming a copper powder products, without cutting, effective utilization of raw materials is high, maximum material savings.

6) Filtration: 5 ~ 50μm.


Technical Parameters for Sintered Metal Powder Filters:


Working Pressure≤31.7Mpa

Working Temperature≤300oC

Medium Viscosity≤260Pa.S

Allow Pressure Drop≤10Mpa

Particle Rentention Rate:5micron

Sintered Metal Powder Filters

Specification of the Sintered Metal Powder Filters



Filtration Rate (μm) BPP
(Pa)
Air Permeability
(l/dm2/min)
Thickness
(mm)
Weight
(g/m2)
Porosity
(%)
Dirt Holding Capacity
(mg/cm2)
3 12300 9 0.35 975 65 6.40
5 7600 34 0.34 600 78 5.47
7 5040 57 0.27 600 72 6.47
10 3700 100 0.32 600 77 7.56
15 2470 175 0.37 600 80 7.92
20 1850 255 0.49 750 81 12.44
25 1480 320 0.61 1050 79 19.38


Production And Sales of Sintered Metal Powder Filters


Sintered Metal Powder Filters can be used for filtering gas, liquid, and fuel oil. It is widely applied in petroleum, chemical, tractor, airplane and ship industries, and also applied as the filter element of pneumatic and hydraulic circuit.
