wedge wire filter nozzles

Product Code: 2865
Category:Water Strainer & Nozzle
Material:stainless steel
Properties:wedge wire screen
Application:water treatment ,oilfield,mining,water well,food,industry,filtration

Email to Us Start Order


Author: Maria
Email:sales@ubooem.com

Description of wedge wire filter nozzles


wedge wire filter nozzles in a nozzle is a screen pipe. Nozzles are closed on one side and have a threaded fitting on the other. One rubber shim, one steel shim and two thin nuts of the same material for a nozzle Material: SUS304, 316,316Letc.

Nozzles can be used for liquid/solid or gas/solid separation, or media retention (sand, catalyst, resin, ...). The nozzles are mounted on a support plate. The dimensions and the distribution of the nozzles on the support plate can be altered to obtain an optimized flow distribution.

Advantage of wedge wire filter nozzles


High strength;
Good resistance to abrasion and corrosion;
High rigidity;
Good in filtration and fluidity;
Flat panel surface;
Fairly well precision and roundness;
Long work time.
Easy to clean and back wash;
Uniform gap.

Uses of wedge wire filter nozzles


The stainless steel screen nozzle with thread coupling can be fixed on the filtering equipment for the filteration of water petrol resin and other medium. Also it can be used in the water treatment, water softhening, conversion of sea water into fresh water, the filter of food chemistry.

Small systems may be built moduarly from off-the-shelf components requiring minimal customization.

wedge wire filter nozzles

UBO is specialized in producing and distributing filter, filter element,polymeric filter,filter strainer,wedge wire screen etc. Welcome to contact us for more information and cooperation.0086-0311-83289301

Specification of the wedge wire filter nozzles


wedge wire filter nozzles

Raw material: stainless steel 304,304L,316,316L,Hastelloy alloy
Outer diameter: min 30mm.
Wedge wire screen length: 30-100mm
Screen slot: 0.02-3mm
Screw thread: Male/Female

wedge wire filter nozzles

No. Type Ton Slot
Opening
Size 0.2-0.25mm slot opening Area of through-flow mm2(reference)

D

L1

L

M

1

SH45-1-C

0.5

0.2-0.5

45

45

95

24

500

2

SH53-2-B

1

0.2-0.5

53

45

100

24

570

3

SH53-2-C

1.5

0.2-0.5

53

50

110

32

700

4

SH57-3-B

2

0.2-0.5

57

45

110

32

600

5

SH70-4-B

3

0.2-0.5

70

55

120

32

1000

Production And Sales of wedge wire filter nozzles


wedge wire filter nozzles

Packaging Details: water-proof bag, carton box, wooden box ( according to your requiement)
Delivery Detail: after payment 25 days! production time schedule will be provided

packing and transport
