Wire Mesh Filter Cylinder

Product Code: 1602
Category:Cylinder Filter
Material:Stainless Steel wire mesh
Properties:Stainless Steel Filter
Application:Filtration,fuel Filter,Hydraulic Filter

Email to Us Start Order


Author: Maria
Email:sales@ubooem.com

Description of Wire Mesh Filter Cylinder


Wire mesh filter cylinder is mainly used for the filtration of air,the medium cleaning and flow control of lubrication oil,hydraulic pressure and air pressure system.



 Any outline size and filtration rating of the wire mesh filter cylinders are available as the requirements of the customer.



Wire Mesh Filter Cylinder has been presented above, want more similar products, please click Filter Cylinder,Stainless Steel Mesh Filter Element,SS Filter Cartridges.



Our Wire Mesh Filter Cylinder is good in quality and competitive in price. We manufacture Wire Mesh Filter Cylinder and supply OEM, ODM service according to your requirement.



If you want more detailed information of this product or related problems, please contact with us, we will reply as soon as possible (general in 24 hours).



Usages for Wire Mesh Filter Cylinder



used to sieving and filter in acid and alkali conditions, oil industry as mud mesh, chemical fiber industry as screen mesh, plating industry as pickling mesh,liquid filtration,including lube,transmission,hydraulic and fuel application.

Features for filter cartridge for high pressure filter in rotary turbo nozzle:

1) Conventional fan-pleat filter element avoids unused volume

2) The laid-over pleat geometry of filter elements maximizes available area and ensures uniform flow distribution throush the filter element.

3) High strength construction(optional)



Benefits of Wire Mesh Filter Cylinder



1) Extended filter element serviced life (same space envelope)

2) Consistent performance throughout filter element service life

3) Reduced filter element and assembly weight weth similar service life and efficiency

Wire mesh filter cylinder

Specification of the Wire Mesh Filter Cylinder


Wire mesh filter cylinder

Nominal Filter Rating

Control Layer

Permeability

Resistance

Bubble Point Pressure

Thickness

Weight

(µm)

(mesh)

(%)

Factor

(mm H2o)

(mm)

(kg/m2)







(cm)







2

325x2400

38

14x105

280-640

1.7

8.4

5

200x1400

38

12x105

250-600

1.7

8.4

10

165x1400

38

7x105

220-550

1.7

8.4

20

165x800

38

4x105

180-450

1.7

8.4

40

50x250

38

4x105

150-400

1.7

8.4

Production And Sales of Wire Mesh Filter Cylinder
