Gravity Fed Boxes

Product Code: 1871
Category:Sieve Bend Screen
Material:stainless steel
Properties:wedge wire screen
Application:Filtration

Email to Us Start Order


Author: Maria
Email:sales@ubooem.com

Description of Gravity Fed Boxes


The gravity fed boxes are typically applied to make coarse separations ahead of the degerminators and in multistage germ washing. The system uses a Vee-Wire dewatering screen to retain the solids while allowing effluent to run through the system. The slurry is gravity fed to the head box and flows to the screen. The solids retained from the screen gather for disposal or reuse.

These gravity fed boxes can be installed easily, and have low operating and maintenance costs. Our team of engineers can work to fit any customer specifications.

Features for gravity fed boxes

Efficient separation with sharp cut;
Unique profile wire welded wege wire sieve bend;
Safe and stand equipment;
Simple screen replacement design;
Pneumatically operated washing jet for screen surface.

Application for gravity fed boxes

They are used in industries such as Sugar, Coal Mining & Quarrying, Mineral Processing, Cement, and Industrial & Urban Effluent Treatment etc. Sieve bend screens are also used as a pre-filter in urban & industrial waste treatment plants to improve the performance of the clarifier by drastically reducing the load. Widely used for fiber removal in Starch industry.

           Gravity Fed Boxes



Announcement:


If you can envision it,We can supply it. TEL:0086-318- 5183240 E-mail:sales@ubooem.com

  Ubo will do everything possible to provide exact and full product information based on metal mesh for your information.

  In order to give customer a clear image of the product,Ubo has taken some pictures, customer can dowmload for reference but using our picture for business is forbidden.

  Due to technique and other factors,product image might be slight different to the products itself,in case everything will follow the products.

  Ubo appreciate any suggestion on our product information or picture or anything else.

Specification of the Gravity Fed Boxes


                             Gravity Fed Boxes



Profile Wire








Width(mm)
1.5
1.5
2.3
2.3
1.8
3.0
3.7
3.3
Height(mm)
2.2
2.5
2.7
3.6
4.3
4.7
5.6
6.3


Support Rod





Round
Width(mm)
2.3
2.3
3.0
3.7
3.3
Ø2.5~Ø5mm
Height(mm)
2.7
3.6
4.7
5.6
6.3


Production And Sales of Gravity Fed Boxes


1.Each product is packed with bubble bag and then few bags to a wooden case (fumigation certificate)
2.We have a very trust forwarding company cooperate for long time and establish a solid partnership,of course,you can also arrange forward to take products from our factory.
