wedge wire screen for centrifuge screen

Product Code: 2436
Category:Centrifuge Screens&Baskets
Material:stainless steel 304,316,316l,320,
Properties:wedge wire screen
Application:water treatment, oilfield, mining, food industry, chemical industry, papermaking industry, decoration.

Email to Us Start Order


Author: Maria
Email:sales@ubooem.com

Description of wedge wire screen for centrifuge screen


Wedge wire screen for centrifuge screen is made by wrapping and welding stainless steel V-shaped profile wire cylindrically around support rods under automatic wire screen machine. Each profile wire and support rod is welded by resistance welding,easily fit for pulp and paper industries for water clarification, cleaning, dewatering, pulp screening and fractionation, and other liquid/solid separation etc.

Uses of wedge wire screen for centrifuge screen

widely used in mining, coal, petroleum, chemical fertilizer, food, environmental protection and other industry to sew sieve net, oil filter, salt industry with mesh.

Features of wedge wire screen for centrifuge screen

Variety and full range of sizes meet the requirements of different coals type, different coals quality; size accurately, the error is small, fixed bolt hole does not appear the wrong eye, partial eye phenomena, to make installment saving time and effort ; welding quality is good, solid structure, does not appear screen welding open, cracking phenomena; uniform screen sewn, smooth screen surface, high opening rate.

wedge wire screen for centrifuge screen

Specification of the wedge wire screen for centrifuge screen


Model NO.

Screen Area

(m2)

Sieve hole size (mm)

Seam Size (mm)

Screen Hole (T/D)

Screen Slot (T/D)

Inlet pulp consistency (%)

Motor Power (Kw)

ZNS0.3

0.3

Φ1.6-Φ3.5

0.1-0.55

50-80

30-50

1-4

22-55

ZNS0.6

0.6

Φ1.6-Φ3.5

0.1-0.55

90-160

60-100

1-4

30-75

ZNS0.9

0.9

Φ1.6-Φ3.5

0.1-0.55

135-250

90-150

1-4

37-90

ZNS1.2

1.2

Φ1.6-Φ3.5

0.1-0.55

180-320

120-190

1-4

45-110

ZNS1.5

1.5

Φ1.6-Φ3.5

0.1-0.55

200-380

140-230

1-4

55-132

ZNS2

2

Φ1.6-Φ3.5

0.1-0.55

260-500

220-300

1-4

75-160

ZNS3

3

Φ1.6-Φ3.5

0.1-0.55

400-700

300-450

1-4

90-220

ZNS4

4

Φ1.6-Φ3.5

0.1-0.55

500-1000

350-730

1-4

132-280

Production And Sales of wedge wire screen for centrifuge screen


transportation



transportation
