Wedge wire screen separation plate

Product Code: 2685
Category:Sieve Bend Screen
Material:stainless steel
Properties:wedge wire screen
Application:Sugar juice filtration

Email to Us Start Order


Author: Maria
Email:sales@ubooem.com

Description of Wedge wire screen separation plate


Wedge wire screen separation plate is the most commonly using screen for filtration and separation in liquid/gas, water wasting, mining, food and so on.

Then have flat type, cylinder type, basket type and slope type according to the screen type. Aslo called flat welded screen panel, cylinder wedge screen and sieve bend screen. They are aslo called woven wedge wire and welded wedge wire according to the weaving type, such as crimped wedge wire, welded wedge screen panels.
Wedge wire screen separation plate  consist of profile wire and support rods with the materials of galvanized steel, low carbon steel and stainless steel 304, 316.

Wedge wire screen separation plate applications include using in chemical, oil, gas, food or beverage, waste water management, mining or coal separation.

Whatever your situation calls for, we can provide you with a Wedge Wire screen designed to your own specifications manufactured from either grade 304 stainless steel or grade 316 stainless steel. Length, width, shape and spacing of profile wire are made to meet your special application requirements.

Wedge wire screen separation plate

Features of Wedge wire screen separation plate

Great strength

Higher capacity

Reduced cost

Higher level of adaptability

Long wear/service life

Reduced maintenance

Greater resistance to corrosive conditions and high temperatures and pressures

Greater resistance to stresses of installation and cleaning

High efficiency fluid-solid separation

Application of Wedge wire screen separation plate

Separating;
Sizing;
Straining;
De-watering;
Filtering;
Drying;
Water intake;
Media retention.

Ubo is specialized in producing and distributing wedge wire screen,lauter tun screens,sieve bend screen,sieve plate screen,water strainer&nozzle,screen nozzles,centrifuge screens and baskets,header-lateral.
Welcome to contact us for more information and cooperation.0086-0311-83289301.

Wedge wire screen separation plate

Specification of the Wedge wire screen separation plate


Specification (Profile wire)

Width(mm): 1 1.5 1.8 2.3 3.0 3.3 3.7 4.0 4.5
Height(mm): 1.5 2.2 2.5 2.7 3.0 3.6 4.0 4.3 4.5 4.7 5.5

Specification (support rods)

Width(mm): 2.0 2.3 2.5 3.0 3.3 3.7 4.0 4.5
Height(mm): 1.5 2.2 2.5 2.7 3.0 3.3 3.6 4.0 4.5 4.7 5.5

Round: From 2.50mm to 6.0mm

Note: other wires and rods available upon request

Slot size

0.05 0.08 0.10, 0.15, 0.20, 0.25, 0.30,1.0,2.0,5.0 ……

45mm also achieved upon request.

Material

Low carton, low carton galvanized steel (LCG), stainless steel (304,316 etc.)

Length

Lengths up to 6 meters.

Diameter

27,50,100,200,500,1000(only for cylinder wedge screen)

End connection

Plain beveled ends for butt welding or threaded

Production And Sales of Wedge wire screen separation plate


Wedge wire screen separation plate
