Wedge Wire screen cylinders

Product Code: 2894
Category:Wedge Wire Screen Cylinders
Material:stainless steel 304,304L,304HC,316,316L,321,430 or as per your request
Properties:Wedge Wire Screen
Application:water-treatment , water well drilling ,oil well drilling ,mineral processing, coal-cleaning plant

Email to Us Start Order


Author: summer
Email:sales@ubooem.com

Description of Wedge Wire screen cylinders



Wedge Wire screen cylindersis used in PP degassing and  recovery plant. It adopts sintered PTFE filter material and SS cage, which overcome the disadvantage of high elongation, big deformation, low resistance to temperature and low anti-corrosion performance for cloth bag.

Advantages for Wedge Wire screen cylinders:


1) Long element service life through highest dirt holding capacities

2) Higher operational dependability through outstanding cleanliness classes

3) Reduced maintenance costs through long replacement intervals

4) Low disposal coats through weight reduction

5) Greater safety through high differential pressure stability



Applications for Wedge Wire screen cylinders:


It is mainly used for macromolecule polymer filtration, high temperature gas filtration, hydraulic system filtration, high-precision ink filtration, pre-filtration of high-precision membrane, catalyst carrier and regeneration, food, drink and pharmaceutical.



Working Principle for Wedge Wire screen cylinders:



Working Pressure≤31.7Mpa

Working Temperature≤300oC

Medium Viscosity≤260Pa.S

Allow Pressure Drop≤10Mpa

Dirt Holding Capacity≥16.9~41Mgcm2

Specification of the Wedge Wire screen cylinders


Wedge Wire screen cylinders


Wedge Wire screen cylinders
Mesh/Inch
Wire Diameter(mm)
Aperture (mm)
Filtration Area %
Mesh/Inch
Wire Diameter(mm)
Aperture
(mm)
Filtration Area%
5
1.00
4.08
64
100
0.11
0.144
32
6
0.90
3.33
62
120
0.09
0.122
33
8
0.70
2.47
61
150
0.065
0.104
38
10
0.50
0.04
64
200
0.05
0.077
37
12
0.50
1.62
59
200
0.04
0.084
47
14
0.50
0.50
52
250
0.04
0.062
37
16
0.35
1.24
61
250
0.035
0.067
43
18
0.28
1.31
64
250
0.03
0.072
50
20
0.35
0.92
52
300
0.04
0.045
28
24
0.35
0.71
45
300
0.03
0.055
42
28
0.35
0.56
38
325
0.035
0.043
30

Production And Sales of Wedge Wire screen cylinders


Wedge Wire screen cylinders
