SS302 Wedge Wire flat screens for gravel

Product Code: 2567
Category:Sieve Plate Screen
Material:SS302
Properties:wedge wire screen
Application:for gravel

Email to Us Start Order


Author: Maria
Email:sales@ubooem.com

Description of SS302 Wedge Wire flat screens for gravel


SS302 Wedge Wire flat screens for gravel can be constructed using rectangular support rods or round support rods. They are the most widely used type of wedge wire screens mainly in the mineral processing both for stationery as well as vibratory decks.

SS302 Wedge Wire flat screens for gravel  can be designed to optimize the open area, strength and wear life for each application. The panels are either continuously or intermittently welded on the lower side of loop to provide complete rigidity to the panels thus becoming very effective in transmitting the vibrations without mechanical failures.

          SS302 Wedge Wire flat screens for gravel

1. Flat Screen with round support rods.
2. Flat Screen with rectangular support rods.
3. Screen Panel with side frame.
4. Heavy duty wedge wire.

  Features of SS302 Wedge Wire flat screens for gravel

Resistant to corrosion and abrasion
Equipped with customer friendly settings
Conform to the safety norm

Application of SS302 Wedge Wire flat screens for gravel



V-wire flat screens is widely used in filters, strainers, architectural screens, water treatment underdrains, media support grids and overlays, infiltration gallery screens, lauter tun screens,
many other liquids, solids separation applications.

Ubo is specialized in producing and distributing wedge wire screen,lauter tun screens,sieve bend screen,sieve plate screen,water strainer&nozzle,screen nozzles,centrifuge screens and baskets,header-lateral.
Welcome to contact us for more information and cooperation.0086-0311-83289301.

Specification of the SS302 Wedge Wire flat screens for gravel


  Slot size (mm): 0.025mm 0.10, 0.15, 0.2, 0.25, 0.30-3mm
Open area: up to 60%
Material: low carbon, low carbon galvanized steel (LCG) steel , stainless steel (304 etc.) Lengths up to 6 meters
Diameter: ranging from 25 to 800mm
End connection: plain beveled ends for butt welding or threaded
Material: Low Carbon Galvanized ( LCG ) and Stainless Steel (SS)
Slot (mm): 0.025 0.1、0.25、0.50、0.75、1.00、1.50、2.00、3.00 and so on.

SS302 Wedge Wire flat screens for gravel

Production And Sales of SS302 Wedge Wire flat screens for gravel


SS302 Wedge Wire flat screens for gravel
