flat plate strainer

Product Code: 2093
Category:Cone Filter&Strainer
Material:Stainless steel 316
Properties:cone filter&strainer
Application:Filtration

Email to Us Start Order


Author: summer
Email:sales@ubooem.com

Description of flat plate strainer


150 psi units designed for full line pressure differential.

300 and 600 psi units designed for 300 psi differential.
May be designed to withstand collapse pressure with cone upstream.
Filtration area is greater than 400% of pipe area. Larger areas available.
Available in mild steel, 304 SS, 316 SS, and other alloys.
Pipe spool sections available.

flat plate strainer

Raised Face Temporary Basket Strainers (Truncated Cone) are available in Carbon Steel, 304SS and 316SS perforated material.
Standard gauge of strainer material ranges between 11 to 22 depending on hole size.  Special thickness are available.
Normally supplied with 1/8“ diameter hole on 3/16“ centers.  Most size of perforations available.  If mesh lined, please specify flow direction.

Heavy Machined Flange (with O-Ring) for seal between strainer basket and strainer housing.
14 ga. (0.078” thick) perforated sheet with ?” dia. holes, 3/8” staggered centers, 40% Open Area is our ‘standard’. The Perforated Strainer Basket can be supplied with any size hole and perforated pattern required.
All SaniClean Basket Strainers are built to accept industry standard Filter Bags. Filter Bags are available in different materials, types of weaves, and ranging in retention rate from 1 – 1500 microns. (See page 10).
Shown with Filter Bag Hold Down Ring
Shown with Quick Release Handle.
For less critical applications heavy machined flange and removable Quick Release Handle Assembly are eliminated. Strainer baskets more cost effective. Replace heavy machined flange with an 11 ga (0.120” thick) OD x ID flange. Replace Quick Release Handle Assembly with a fixed handle. No O-Ring seal between strainer basket and the strainer housing.

Specification of the flat plate strainer


TYPE

Nominal Micron

um

Working Micron

um

Air Permeability

L/min*cm2*pa

Bubble Point Pressure

Pa

XL-SW1

1

6-7



5300-6000

XL-SW2

2

8-9

(1-6)*10-4

4300-5000

XL-SW5

5

11-13

(6-10)*10-4

3000-3700

XL-SW10

10

16-18

(6-10)*10-4

2700-3300

XL-SW15

15

24-26

(1-6)*10-3

2000-2600

XL-SW20

20

28-32

(1-6)*10-3

1800-2300

XL-SW25

25

34-36

(6-10)*10-3

1400-1900

XL-SW30

30

40-45

(6-10)*10-3

1200-1700

XL-SW40

40

50-55

(1-6)*10-2

1000-1500

XL-SW50

50

71-80

(1-6)*10-2

900-1200

XL-SW70

70

86-95

(6-10)*10-2

700-1100

XL-SW100

100

110-120

≥5*10-2

650-1000

XL-SW150

150



≥5*10-2



XL-SW200

200



≥8*10-2



XL-SW300

300



≥8*10-2
