Brass Mesh Circular Cone Filter

Product Code: 1642
Category:Cone Filter&Strainer
Material:Brass Mesh
Properties:stainless steel filter
Application:Filtration,fuel Filter,Hydraulic Filter

Email to Us Start Order


Author: Maria
Email:sales@ubooem.com

Description of Brass Mesh Circular Cone Filter


Brass Mesh Circular Cone Filter,1. C2680 Brass Wire of 0.18(dia.)mm 60 Mesh.,2. Lead-free alloy is used for the seam spot.,3. The opening of Mesh is 0.24.,4. The shape of Circular cone.,5. This is for oil cleaning filter.,6. The Brass Ring is from metal cutting work.,



Weaving character: Plain weave and twill weave.

Characteristics of Brass Mesh Circular Cone Filter

Acid-resisting, alkali-resisting, heat-resisting, wear-resisting etc.

Uses of Brass Mesh Circular Cone Filter

used in mine, oil, chemical industry, food industry, pharmaceuticals industry and machine producing and filtering industry.

Feature of Brass Mesh Circular Cone Filter

1.Superior flow rate
2.Excellent performance
3.Wide chemical compatibility
4.Low environment impact
5.Experiencing 100% integrity test before ex-factory

Brass Mesh Circular Cone Filter

Specification of the Brass Mesh Circular Cone Filter




Specification of Brass Wire Mesh



Brass Wire Mesh

Mesh/Inch

SWG ( wire gauge)

Aperture (mm)

8meshx8mesh

24

2.616

10meshx10mesh

24

1.98

12meshx12mesh

26

1.66

14meshx14mesh

26

1.357

16meshx16mesh

30

1.27

18meshx18mesh

30

1.096

20meshx20mesh

32

0.88

30meshx30mesh

34

0.613

40meshx40mesh

38

0.485

50meshx50mesh

39

0.378

60meshx60mesh

40

0.301

70meshx70mesh

41

0.251

80meshx80mesh

42

0.216

90meshx90mesh

43

0.191

100meshx100mesh

43

0.164

120meshx120mesh

45

0.140

140meshx140mesh

45

0.110

160meshx160mesh

46

0.087

Width: 0.6m-1.3m
