Pressure Filter Leaves

Product Code: 2117
Category:Leaf Filters
Material:Stainless steel 316L
Properties:leaf filters
Application:Filtration

Email to Us Start Order


Author: summer
Email:sales@ubooem.com

Description of Pressure Filter Leaves


The Pressure Filter Leaves consists of filter disc and strainer, mainly used to filter impurities from spinning dope, which exist in front side of spinneret of spindle, for synthetic fiber and artificial fiber in chemical fiber industries, in order to make sure unblock spinneret holes, improve spinning dope purity, and guarantee spinning quality.

The Pressure Filter Leaves is mainly used to filter biaxial oriented polyethylene terephthalate (BOPET) during production. These disc filters have excellent structure, high strength and lower resistance performance.

Pressure Filter Leaves
CHARACTERISTIC OF Pressure Filter Leaves

Filter Precision: 2~300um

Heat Resistance: -200°c ~~650°c continous filtration

Cleaning: back-washing, easy cleaning.

Specification:Dia:53mm,70mm,90mm,120mm,160mm,

mesh:50-400 per inch

APPLICATION OF Pressure Filter Leaves

1. Decentralied &Cooling Material for Higher Ambient Temperature

2.Gas Distrbution Material

3.High Temperature Filtration Material

we can design special dimension according to customer demands

Specification of the Pressure Filter Leaves


Mesh
Wire Diameter
Micron Absolute
Micron Nominal
12*64
.023/.0165
270~290
200
14*88
.020/.013
220~240
150
24*110
.015/.010
115~123
80
50*250
.0055/.0045
56~63
40
40*200
.007/.0055
70~75
55
80*400
.0049/.0028
40~45
35

Note: We can design and fabricate according to customer requirements
