Wedge wire screen size and types

2022-08-29Tags:Wedge wire screen size and types: 304,304L,316,316L,Posted By zhaozhao

In recent years a demand has grown for wedge wire assembled by welding, in contrast to the looped method.


Using specially developed machinery and advanced automatic welding our welded type screens offer a wide range of apertures with clear and unobstructed open area.

Flat Top:

The most commonly used profile giving good screening efficiency over the whole range in most applications. It is excellent for the de-watering of slurries and is extensively used in coal washeries.

Conical top:

Designed particularly for fine mesh screens for de-watering of slurries.

Square top:

Suitable for larger aperture screens used with highly abrasive materials.

In addition,reinforcements can be added as required providing the strongest and most cost effective welded wedge wire screen on the market. Usual materials are stainless steels in stainless steel 304,304L,316nd 316L . Other metals are available – please call to custom.
