Melt Filter Element

Product Code: 1683
Category:Metal Sintered Filter Elements
Material:Stainless Steel sintered mesh,,Metal Fiber
Properties:Sintered filter
Application:Filtration

Email to Us Start Order


Author: summer
Email:sales@ubooem.com

Description of Melt Filter Element


Melt Filter Element will permit the straining or filtering of a wide variety of fluids, to retain solids of almost any size. All baskets filters are easily removable and cleanable. Melt Filter Element can be offered in single cylinder, double cylinder, multi cylinder and pleated design depend upon requirement of application. They are constructed of filter housing, Melt Filter Element supported with perforated cage, positive sealing arrangement to avoid any bypass & choice of end connections.
Filter Media: Filter media for basket filters include stainless steel perforated sheet, stainless steel weaving wire mesh and stainless steel sintered wire cloth. As to external dimensions and filter rating, we may also provide products per customers requirements.

Melt Filter Element

Application for Melt Filter Element:

Melt Filter Element are mainly used in such industries as petroleum, chemical industry, food, beverage, water treatments, etc.
Operation for Stainless Steel Perforated Multi-Layer Filter Elements Basket Filter:
Unfiltered liquid enters the basket housing and passes down through them. Solid are contained inside / outside of basket depend upon design and removed when the unit is serviced. They are available with in situ backwashing arrangement, where it does not required removing baskets for cleaning, often.
Basket filters normally supplied with spring arrangement at top of filter element. This will ensure any type of bypassing & confirm the position of basket, even in case of reverse flow. Fluid bypass around the basket is prevented by an optional O-Ring seal between the basket rim and the housing id.

Features & Benefits for Melt Filter Element:

Large-area, heavy-duty baskets.
Low pressure drops.
Housing are permanently piped.
Covers are O-Ring sealed.
Carbon steel, or stainless steel (304 Or 316) housing.
Easy to clean.
Option of in situ backwashing.
Filtration rating available from 5 micron to 2000 micron & more.

Specification of the Melt Filter Element


flange size (inch )
pipe size inside diameter outside diameter (class 150-1500)
500/300 300 600 900 1500
3/4 5/8 2-1/8 2-1/2 2-1/2 2-5/8 2-5/8
1 3/4 2-1/2 2-3/4 2-3/4 3 3
1-1/2 1-1/4 3-1/4 3-5/8 3-5/8 3-3/4 3-3/4
2 1-3/4 4 4-1/4 4-1/4 5-1/2 5-1/2
2-1/2 2-1/4 4-3/4 5 5 6-3/8 6-3/8
3 2-3/4 5-1/4 5-3/4 5-3/4 6-1/2 6-3/4
4 3-3/4 6-3/4 7 7-1/2 8 8-1/8
5 4-5/8 7-5/8 8-1/4 9-3/8 9-5/8 9-7/8
6 5-1/2 8-5/8 9-3/4 10-3/8 11-1/4 11
8 7-3/8 10-7/8 12 12-1/2 14 13-3/4
10 9-3/8 13-1/4 14-1/8 15-5/8 17 17
12 11 16 16-1/2 17-7/8 19-1/2 20-3/8
14 12-1/4 17-3/8 18-7/8 19 20-3/8 22-5/8
16 14 20-1/8 21 21-7/8 22-1/2 25-1/8
18 15-3/4 21-1/4 23 23-3/4 25 27-5/8
20 17-1/2 23-1/2 25-1/2 26-5/8 27-3/8 29-5/8
24 21-1/4 27-7/8 30-1/4 30-7/8 32-7/8 35-3/8
30 27-1/4 34-3/8 37-1/8 37-7/8 39-3/8 -
36 33 40-7/8 43-5/8 44-1/8 46-7/8 -

Production And Sales of Melt Filter Element


Melt Filter ElementMelt Filter Element
