Header Hub Lateral

Product Code: 1821
Category:Header-Lateral
Material:Stainless Steel
Properties:Wedge Wire Screen
Application:Filtration,water treatment,industry filtration

Email to Us Start Order


Author: Maria
Email:sales@ubooem.com

Description of Header Hub Lateral


They Provide even distribution or collection and avoid flow/pressure concentrations such as dead zones, wall effects or channeling. Hub Laterals can be designed for disc head vessels enabling the system to collect completely to the bottom of the vessel. Header laterals design is also available for flat bottom vessel distributor or collector applications All systems are designed for effective liquid or solid retention in a wide range of applications including ion exchangers, clay and sand filtration applications, carbon towers and power plants with water systems. Available as both Header Lateral and Hub lateral assemblies, wedge wire screen laterals and pipe based laterals can be connected to headers or hubs by the following methods : -standard NPT threaded connections -flanged connections. fabricated or ANSI -welded as one assembly Laterals are available in all standard pipe and tube outside diameters.

Application of Header Hub Lateral

wedge wire type hub and header lateral consist of a series of screen laterals connected to either a central-header pipe or a hub, they are important components of ion exchange units, media filters, sand filters, carbon strip vessels, carbon towers, clay filters and in many water and waster water treatment applications.

Header Hub Lateral

Announcement:

If you can envision it,We can supply it. TEL:0086-0311- 83289301 E-mail:sales@ubooem.com

·          Ubo will do everything possible to provide exact and full product information based on metal mesh for your information.

·          In order to give customer a clear image of the product,Ubo has taken some pictures, customer can dowmload for reference but using our picture for business is forbidden.

·          Due to technique and other factors,product image might be slight different to the products itself,in case everything will follow the products.

·          Ubo appreciate any suggestion on our product information or picture or anything else.

Specification of the Header Hub Lateral


Length L1
Slot  mm
AMD 4
AMD 6
AME 6
AMD 8


Ф=MM
82
0.05
0.1
0.2
0.3
0.5
1
258
259
258

113
316
321
316

144
374
383
374

175
432
445
432

206
491
507
491
520
237
549
569
549
580
268
607
631
607
640
299
665
693
665
699
330
724
755
724
759
361
782
817
782
819
392
840
879
840
879
423
898
941
898
939
454
957
1003
957
999
485
1015
1065
1015
1059
516
1073
1127
1073
1119
547
1131
1189
1131
1179
578
1189
1251
1189
1239
609
1247
1313
1247
1299
640



1359
671



1419
702



1479
733



1539
