Expanded Metal Cylinder Filter

Product Code: 2578
Category:Cylinder Filter
Material:Stainless Steel wire mesh
Properties:stainlesss steel filter element
Application:water-treating equipment;the environment protection; the sea water transforms into the industrial water and life use water desalination treatment

Email to Us Start Order


Author: summer
Email:sales@ubooem.com

Description of Expanded Metal Cylinder Filter


Expanded metal cylinder filter adopts sintered stainless steel fiber felt, has high-pressure, high temperature and chemical corrosion resistance. It also has good air permeability, high dirt holding capacity and long-life service time can repeat use by clean, is the ideal filter element for petroleum, chemical and synthetic fiber industries.

Expanded metal cylinder filter


Advantage for Expanded Metal Cylinder Filter:


1) Long element service life through highest dirt holding capacities

2) Higher operational dependability through outstanding cleanliness classes

3) Reduced maintenance costs through long replacement intervals

4) Low disposal coats through weight reduction

5) Greater safety through high differential pressure stability


Application for Expanded Metal Cylinder Filter:


It is mainly used for macromolecule polymer filtration, high temperature gas filtration, hydraulic system filtration, high-precision ink filtration, pre-filtration of high-precision membrane, catalyst carrier and regeneration, food, drink and pharmaceutical.


Features for Expanded Metal Cylinder Filter:


1) hydraulic backflushing filter for coal mine

2) material:stainless steel sintered

3) different filtration precisions according to client's requirement

4) compact structure

5) excellent performance

6) back flush filter element

7) certification ISO9001:2008

8) corrosion resistance

9) easy to install,sample is available

10) OEM product is welcomed

Specification of the Expanded Metal Cylinder Filter


Filtering
Level
Filtration
Precision
um
Maximum
Hole
Diameter um
Permeability
M3/h.㎡.kpa

Thickness
mm
Compression
Strength
Mpa/cm2
S9
0.2
2.5
1.5
3
3.0
S8
0.5
4
3
3
3.0
S7
1.5
6
5
3
3.0
S6
2.5
10
15
3
3.0
S5
5
15
40
3
3.0
8
20
80
3
3.0
S4
10
30
120
3
3.0
S3
28
60
250
3
3.0
35
80
500
3
3.0
S2
40
100
800
3
3.0
S1
65
160
1000
3
3.0


Production And Sales of Expanded Metal Cylinder Filter



Expanded metal cylinder filter
