Medical and pharmaceutical Felt Filter Elements

Product Code: 1680
Category:Metal Sintered Filter Elements
Material:stainless steel 304,304L,304HC,316,316L,321,430 or as per your request.
Properties:Sintered filter
Application:mining, coal, petroleum, chemical fertilizer, food, environmental protection and other industry to sew sieve net, oil filter, salt indu

Email to Us Start Order


Author: Jane
Email:sales@ubooem.com

Description of Medical and pharmaceutical Felt Filter Elements


Medical and pharmaceutical Felt Filter Elements is made with thin filaments of nonwoven stainless steel. These porous metal felt filter elements are ideal for high pressure, highly corrosive, highly viscous or radioactive applications. They feature extremely high porosity (up to 85%), high flow rates (up to 20 times higher than other media types), and very long life.

Random fiber filtration (Medical and pharmaceutical Felt Filter Elements) can provide absolute particle retention, longer on stream time and high dirt-holding capacity for under 60 micron filter elements. Although more expensive, it oftens offers clear advantages over wire cloth, sintered metal or non-metallic fibers. Its high temperature, high pressure and corrosion resistance combined with almost unemetal felt filter elements have a random matrix of 316-L stainless steel filaments with diameters from 4 to 25 microns. The finer the micron, the more open area is provided in a pure crosshatch pattern.



Application for Medical and Pharmaceutical Felt Filter Elements:



oil well, water well, geothermal well, sewage and industrial wastewater disposal plants, food equipment, liquids filtration, cleaning treatment



Advantages for Medical and Pharmaceutical Felt Filter Elements:



Low pressure drop: The high porosity of our metal fiber media allows a very low pressure drop (and thus lower energy cost), even at high filtration velocities

Ease of cleaning: The open structure of porous metal media allows you to clean in situ by backpulsing or backwashing

High strength: The sintering process creates strong fiber bonds and guarantees a high strength filter medium. Combined with an appropriate inner core, our filter elements can withstand thermal shock, high pressures, and frequent backpulsing.

Heat & corrosion resistance: Our filter media can be used in high temperature (up to 1000° C, depending on the alloy) and/or corrosive applications - where non-metallic textile, ceramic or polymer products fail

Can be used for surface or depth filtration. Our filter media enables you to achieve high efficiencies through a cake build-up (surface filtration) and also offer high dirt holding capacity for depth particles capture (depth filtration)
Stainless steel and other alloys available: not brittle, chemical cleaning is possible, weldable, low thermal expansion, maintains structure (no thermal shock) Depending on the performance you require, we select the proper alloy to provide the required resistance and strength

Medical and pharmaceutical Felt Filter Elements

Specification of the Medical and pharmaceutical Felt Filter Elements


Nominal Grade filter mesh mean pore Filtration Ratings (microns)
2 325*2300 5 2
5 200*1400 10 5
10 165*1400 15 10
20 165*800 20 20
40 325*325 43 40
60 250*250 61 55
80 200*200 74 75
100 150*150 104 100

Production And Sales of Medical and pharmaceutical Felt Filter Elements


Package: in wood case

Delivery Time: 5-25 days
