Metal mesh leaf filter

Product Code: 1785
Category:Leaf Filters
Material:Metal mesh
Properties:Filter disc
Application:Filtration

Email to Us Start Order


Author: summer
Email:sales@ubooem.com

Description of Metal mesh leaf filter


The Metal mesh leaf filter consists of filter disc and strainer, mainly used to filter impurities from spinning dope, which exist in front side of spinneret of spindle, for synthetic fiber and artificial fiber in chemical fiber industries, in order to make sure unblock spinneret holes, improve spinning dope purity, and guarantee spinning quality.
The Metal mesh leaf filter is mainly used to filter biaxial oriented polyethylene terephthalate (BOPET) during production. These disc filters have excellent structure, high strength and lower resistance performance.

Metal mesh leaf filter



The Metal mesh leaf filter has been widely used in transfomer oil, turbine oil, hydraulic oil, aviation kerosene, petrolum, chemical, power plant, coal carbon, mining, pharmaceutical, food and engineering industries.

Characteristics for Metal mesh leaf filter:

Made by stretching and drawing through moulds, the product is characterized by acid-alkali resistance, high tensile strength, intercrystalline corrosion resistance, smooth surface and bright color.

Performance for Metal mesh leaf filter:

Acid resistance, alkaline resistance, high temperature resistance, strong tension, and good abrasion resistance.Metal mesh leaf filter

Specification of the Metal mesh leaf filter


Mesh
Wire Diameter
Micron Absolute
Micron Nominal
12*64
.023/.0165
270~290
200
14*88
.020/.013
220~240
150
24*110
.015/.010
115~123
80
50*250
.0055/.0045
56~63
40
40*200
.007/.0055
70~75
55
80*400
.0049/.0028
40~45
35

Note: We can design and fabricate according to customer requirements

Production And Sales of Metal mesh leaf filter


Metal mesh leaf filterMetal mesh leaf filter
