Y-type filter and selection principles outlined


2019-02-13Tags:Y-type filter,Posted By zhaozhao

Y-type filter Overview
A filter is a device on the pipeline indispensable medium, usually installed in the valve, pressure relief valve, water valve or other device inlet end, used to eliminate impurities in the medium, in order to protect the valves and equipment normal use.
Y-type filter selection principle
1、the import and export path: import and export filters in principle should not be less than the diameter of supporting the pump inlet diameter, generally consistent with the import pipeline caliber.
2、Pressure: according to the highest possible pipeline pressure filter to determine the filter pressure rating.
3、Select the mesh hole: the main consideration the need to intercept the particle impurities, according to media process technology requirements. A variety of particle sizes can be blocked screen check under the table "filter specifications."
4、the filter material: filter material is generally connected with the selection process piping material the same conditions of service for different choice could be considered cast iron, carbon steel, low alloy steel or stainless steel filter.
