Spin-on Filter Elements

Product Code: 2074
Category:Cylinder Filter
Material:Stainless steel 302,304,304L,316,316L
Properties:cylinder filter
Application:Filtration in Oil,Chemical,Pharmacy Industry

Email to Us Start Order


Author: summer
Email:sales@ubooem.com

Description of Spin-on Filter Elements


Spin-on Filter Elements


 high performance replacement Spin-On filter products are dimensionally and functionally interchangeable with Pall® HC 7500 and Parker® 50 AT/50 AT-2 Series filters

Temperature Range: -65°F to +250°F
Maximum Operating Pressure: 200 psi
Maximum pressure without bypass: 80 psi
Beta Rated SWIFTGLASS: 1,3,6,10, & 25 Micron
Application: Petroleum based fluids only. Call SWIFT for synthetic fluids
Buna “N” Gasket standard. Fluorocarbon Gasket optional,

Spin-on Filter Elements

Specification of the Spin-on Filter Elements




Removal Rating — ISO 457



Grade

βx≥200

1

1µm

3

3µm

6

6µm

12

12µm

25

25µm

Removal Rating — ISO 1688



µm(c) Rating for Beta Value

Grade

2

10

75

100

200

1000

1

‹2

‹2

‹2

‹2

2.0

2.5

3

‹2

‹2

3.1

3.3

3.8

5

6

2.1

3.4

5.0

5.2

5.7

7

12

3.2

5.5

8.3

8.7

9.7

12

25

7.2

11.0

15.8

16.5

18.2

22

Table A
Media Options
Micron Rating @ βx≥ 200
Micron Code Micron Rating
50 1 micron
60 3 micron
70 6 micron
80 12 micron
90 25 micron
Table B
Length Code Length (inches)
Omit / Blank 6.7"
E (Extended Cart) 10.7"



Part Number = SF5 + (Micron Code from Table A) + MG + (Length Code from Table B)

Part Number Examples
SF560MG — 500 series, 3 micron (6.7" standard can)
SF560MGE —500 series, 3 micron (10.7" extended can)

Production And Sales of Spin-on Filter Elements


Spin-on Filter ElementsSpin-on Filter Elements
